Two kinds of pages lend themselves to specialized tooling: API references and diagrams. This page covers how GitDocAI generates an API Reference from an OpenAPI/Swagger spec, the components you'll use to refine the result, and how to draw Mermaid diagrams anywhere in your docs.

Building an API Reference

To create an API Reference, add a new section and pick OpenAPI / Swagger as the source type in the wizard. From there you can either upload the spec file directly or point at a file inside a connected GitHub repository.

GitDocAI parses the spec deterministically — no AI interpretation — and creates one page per endpoint, populated with its method, path, parameters, request/response shapes, and example payloads. What's in your spec is exactly what ends up in your docs; nothing is hallucinated or reordered.

Keeping the reference in sync

When your spec changes, trigger a re-sync from the section's Source sidebar. GitDocAI compares the new spec against the previous one and stages the differences — added, removed, or modified endpoints — as pending proposals. A dedicated spec-diff view shows exactly what changed before anything touches your live content, and you can accept or reject changes endpoint-by-endpoint.

See Re-sync & Pending Changes for the full review flow.

Refining a generated page

Endpoint

The header of an API page. Displays the HTTP method and path prominently at the top so readers immediately know what they're looking at.

Attributes: method (required), path (required).

MDX:

<Endpoint method="POST" path="/api/v1/documentations" />

Preview:

ParamField

Documents a single request parameter, query param, path param, or body field. You can nest Markdown inside to provide a detailed description — including backticks, links, or other components.

Attributes: path (required), type (required), required (boolean, adds a "required" badge).

MDX:

<ParamField path="name" type="string" required>
  The name of the documentation. Must be unique within your organization.
</ParamField>

<ParamField path="audience" type="string">
  Either `public` or `private`. Defaults to `public`.
</ParamField>

Preview:

Response

Documents one possible API response, grouped by HTTP status code. Typically you'll see one for success (200 or 201) plus the common error codes (400, 401, 404, 500).

Attributes: status (required), description (optional short summary).

MDX:

<Response status="201" description="Documentation created successfully.">
  ```json
  {
    "id": "doc_abc123",
    "name": "My Docs",
    "status": "pending"
  }
  ```
</Response>

<Response status="400">
  The request body is invalid. The response includes a `message` field explaining the error.
</Response>

Adding multi-language code examples

OpenAPI specs don't usually include client code samples. Once a page is generated, you can add them yourself with <CodeGroup> — a tabbed interface built for code that lets readers flip between curl, JavaScript, Python, and any other language you want to support.

MDX:

<CodeGroup>

```bash curl
curl -X POST https://api.example.com/v1/docs
  -H "Authorization: Bearer $TOKEN"
```

```js JavaScript
await fetch("https://api.example.com/v1/docs", {
  method: "POST",
  headers: { Authorization: `Bearer ${token}` }
});
```

```python Python
requests.post(
  "https://api.example.com/v1/docs",
  headers={"Authorization": f"Bearer {token}"}
)
```

</CodeGroup>

Visualizing workflows with Mermaid

Any time a visual is clearer than prose — but you don't want to maintain a static image file — use Mermaid. Mermaid lets you write text-based diagrams that render directly as SVGs. You can drop a Mermaid block inside any page, including API reference pages.

Supported diagram types

Syntax rules

• No ampersands: always use and instead of & in your labels.

• Quote special characters: never put ( or ) directly inside brackets [ ]. Wrap the label in double quotes instead.

  • Bad: A[Log Management (SIEM)]

  • Good: A["Log Management (SIEM)"]

• Avoid HTML: do not use <, >, or other HTML-like characters in your labels.

Example: a generation flowchart
